Technical Information: Application:
Long service life and high efficiency in industrial and
automotive applications.
Compact design, optimised for work in confined spaces
Maximum loosening torque: 4100 Nm
Exhaust air is guided through the handle downwards
Reduced vibrations
Easy handling
Short design – only 184 mm
Strongest HAZET impact wrench ever
Including hand grip
HAZET Twin Turbo technology – high torques with compact
design
Innovative 8-blade air motor with 25% higher impact
performance ensures maximum torques
One-hand operation for right and left-handed users
Powerful twin hammer mechanism
Air connection inlet: Inside thread 16.41 mm (3/8″)
Recommended torque: 1890 Nm
Hose diameter (recommended): 13 mm
Working pressure (bar): 6.3
Sound power level: 110.5 db(A) Lp W
Vibration acceleration: 10.69 m/s2
Loosening torque (max) determined with screw size M: 32
Forward and reverse: two-stage (forward), single-stage
(reverse)
Cold insulated handle
Output: Square, solid 20 mm (3/4 inch)
Net weight: 4.5 kg
Tightening torque max.: 2170 Nm
Maximum loosening torque: 4100 Nm
Sound pressure level: 99.5 dB(A) Lp A
Revolutions per minute: 5200
Air requirement: 147.2 l/min (2.5 l/sec)
