Tehniline informatsioon: Application:
Material-friendly wheel mounting or dismounting (alloy
rims) Wrench size 17 mm
Plastic insert to protect the surface of the wheel bolts
Additionally with rotating outside plastic sleeve (except
903 S Lg-22) (replaceable) to protect the rims when
screwing the wheel bolts
Optimised contours for deeper rim holes in e.g. AUDI
S-Line, AMG, OZ etc.
Plastic sleeve blue
Colour-coded plastic sleeve facilitates finding the correct
size
Long design
With borehole for locking pin or safety spring and grove
for O-ring
Surface: phosphatized, oiled
DIN 3124, ISO 2725-2
Made in Germany
Drive: Square, hollow 12.5 mm (1/2 inch)
Output: Outside hexagon Traction profile
Wrench size: 17
Dimensions / length: 85 mm
Diameter d1 (output side): 30 mm
Diameter d2 (drive side): 30 mm
Net weight: 0.24 kg
903 S Lg-22 without plastic insert. Outside plastic sleeve
non-rotatable
